Stainless Steel 347 Round Bar
ASTM A276 347 SS Rod
Stainless Steel 347 Bars & Rods
Creative Piping Solutions Private Limited is one of the oldest and leading manufacturers and stockists of 347 Stainless Steel Round Bars and Rods based in Mumbai, India. We are a first 347 SS Flat and Square Bar Suppliers that manages a huge inventory for sale to our esteemed buyers. Our clients use UNS S34700 Round Bars for applications in walls, concrete footings, beams, and for ornamental work among others. The increased corrosion protection of AISI 347 Stainless Steel Bright Hex Bars permits it to be used in different industries including the electrical and construction sector. JIS SUS 347 Square Bars are a highly demanded product from our range due to its resistance to corrosion and many organic chemicals.
Alloy 347 is a general-purpose austenitic Stainless steel with a face-centered cubic structure. It is essentially non-magnetic in the annealed condition and can only be hardened by cold working. Niobium has been added to suppress grain boundary Chromium Carbide precipitation.
We supply 347 Stainless Steel Black Bars are known for its increased corrosion resistance, strength, and high fabrication ability. To satisfy the needs of our clients, We deliver SS 303 Cold Drawn Bars, Polished Round Bars, and Black Forged Bar in various thicknesses, sizes, and designs that fit our buyer’s exact specifications. We are suppliers and exporters of SS 347 Steel Hexagonal Bars, Threaded Bars, Hot Rolled Flat Bars, and Cold Rolled Square Bars in various thickness, sizes, and specification to a wide range of sectors because of the high level of quality products we are offering them they get maximum benefits. We Supply all types and shapes of Bars and Rods in varied countries like Bahrain, Kuwait, Iraq, Singapore, Oman, Qatar, Saudi Arabia and the United Arab Emirates (UAE).
Popular Product Searches on Creative:
Square Bars | Forged Round Bar | Steel Hex Bar | Polish Bar | Bright Round Bars | Black Round Bars
| Specifications | ASTM A276, ASME SA276 / ASTM A479 ASME SA479 |
| Product | 347 Round Bar |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 4mm to 500 mm |
| Length | 1 to 6 Meters, Custom Cut Length |
| From | Round, Square, Rectangle, Hex (A/F), Ingot, Billet, Forging Etc |
| Finish | Black, Rough Turned, Bright Polished, No 4 Finish, Matt Finish, BA Finish |
| Bright Bars Size | OD: 4mm to 100mm |
| Hex Bars Size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars Size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars Size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Angle bars Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bars Size | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar Size | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Condition | Hardened & tempered, annealed |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Price Terms | Ex-Works, FOB, CFR, CIF, CNF |
| Latest Price | Call +91 7045212326 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 347 | 1.4550 | S34700 | SUS 347 | – | 08Ch18N12B | – | X6CrNiNb18-10 |
| 347 SS Polished Round Bar | Stainless Steel 347 T-Bar |
| WERKSTOFF NR. 1.4550 Square Bar | 347 SS Triangle Bar |
| ASME SA276 347 SS Flat Bar | ASME SA479 347 SS Hex Bar |
| 347 SS Hollow Bar | UNS S34700 Round Bar |
| 347 SS Precistion Ground Bar | ASTM A276 347 Threaded Bar |
| 347 SS AISI Rebar | JIS SUS 347 True Bar |
| 347 SS Cold Drawn Bar | 347 SS Hot Rolled Bar |
| ASTM A479 347 SS Rods | DIN 1.4550 Half Round Bar |
| EN X6CrNiNb18-10 Polish / Bright Bar | 347 Stainless Steel Black Bar |
| 347 Stainless Steel Angle Bar | GOST 08Ch18N12B Forged Bar |
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
|---|---|---|---|---|---|---|---|---|---|
| SS 347 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 17 – 20 | 10xC – 1.10 | 9.0-13.0 | 62.74 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Flat Bar | |||
|---|---|---|---|
| sizes in mm | Size (inch) | Thickness (mm) | Thickness (in Inches) |
| 22 | 7/8 | 17 & 18 | 2/3 – 5/7 |
| 25 | 1 | 5 to 20 | 3/16 – 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 – 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 – 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 – 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 – 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 – 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 – 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 – 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 – 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 – 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 – 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 – 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 – 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 – 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
| Square bar – metric sizes and weights | ||
|---|---|---|
| Square bar Size | KG’s per Metre | Standard Length (metres) |
| 10 x 10 | 0.81 | 6.0 |
| 12 x 12 | 1.16 | 6.0 |
| 16 x 16 | 2.06 | 6.0 |
| 20 x 20 | 3.22 | 6.0 |
| 25 x 25 | 5.03 | 6.0 |
| 32 x 32 | 8.24 | 6.0 |
| 40 x 40 | 12.8 | 6.0 |
| 50 x 50 | 20.12 | 6.0 |
| Documents like QAP | Packaging list |
| NABL approved lab test report | Guarantee letter |
| Buyers report | Third-party test report |
| Raw material test report | Material Traceability report |
| Commercial invoice to buyers | The TC like MTC as per EN 10204/3.1B |
Creative Piping Solutions Private Limited is focusing on every procedure to assure quality. AISI SS 347 Bars are subject to surface wash and cleaning to remove all impurities. After that bars and rods are wrapped in thin plastic. Then an outer rope is tied to protect the Stainless Steel Grade 347 Bar and they are packed in a container or wooden box.
