Stainless Steel 317 Round Bar
ASTM A276 317L SS Rod
Stainless Steel 317 Bars & Rods
Creative Piping Solutions Private Limited is acknowledged as a manufacturer and one of the biggest Stockists of 317 SS Round Bars and Rods in Mumbai, India. 317L SS Round Bars and Rods are available in a variety, materials, and finishes, in metric and inch sizes to complete any small or large quantity orders from our customers. Our stock in stainless steel 317 round bar ranges from 1/8″ to 24″ in diameters. Ideal for a wide variety of home and commercial applications, UNS S31700 exhibits excellent corrosion resistance and has a high ease of fabrication, outstanding formability. The austenitic UNS S31703 stainless steels flat and square bars, also known as 18 / 8 for its composition of 18 % chromium and 8 % nickel and it resist corrosion in atmospheric and pure water environments.
Stainless steel JIS SUS 317L is a low carbon version of grade 317 stainless steel. 317L SS Round Bars have the same high strength and corrosion resistance as 317 steel but can produce stronger welds due to the low carbon content. WERKSTOFF NR. 1.4449 stainless steel is a modified version of 316 stainless steel. It has high strength and corrosion resistance. Grade 317 stainless steel is used in the applications: Pulping paper, Textile, Chemical equipment.
We have gained rich industry experience in the field of supplying and Exporters a huge gamut of Round Bars, Rods, Hex Bars, Forged Bars, Square Bars, Threaded Bars, Flat Bars, Black Bars, True Bars, Hexagon Bars, Hot Rolled Round Bars, Polished Bars, Cold Drawn Bars, Rectangular Bars, Bright Bars, Ground Bars, Angle Bars, T Bars (Tee), Hollow Bars in the United Arab Emirates (UAE), Bahrain, Singapore, Oman, Kuwait, Iraq, Qatar, and Saudi Arabia at industrial leading prices.
Popular Product Searches on Creative:
Square Bars | Forged Round Bar | Steel Hex Bar | Polish Bar | Bright Round Bars | Black Round Bars
| Specifications | ASTM A276, ASME SA276 / ASTM A479 ASME SA479 |
| Product | 317/317L Round Bar |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 4mm to 500 mm |
| Length | 1 to 6 Meters, Custom Cut Length |
| From | Round, Square, Rectangle, Hex (A/F), Ingot, Billet, Forging Etc |
| Finish | Black, Rough Turned, Bright Polished, No 4 Finish, Matt Finish, BA Finish |
| Bright Bars Size | OD: 4mm to 100mm |
| Hex Bars Size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars Size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars Size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Angle bars Size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bars Size | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar Size | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Condition | Hardened & tempered, annealed |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Price Terms | Ex-Works, FOB, CFR, CIF, CNF |
| Latest Price | Call +91 7045212326 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 317 | 1.4449 | S31700 | SUS 317 | – | – | – | – |
| SS 317L | 1.4438 | S31703 | SUS 317L | – | – | – | – |
| 317 SS Polished Round Bar | Stainless Steel 317 T-Bar |
| WERKSTOFF NR. 1.4449 Square Bar | 317 SS Triangle Bar |
| ASME SA276 317 SS Flat Bar | ASME SA479 317 SS Hex Bar |
| 317 SS Hollow Bar | UNS S31700 Round Bar |
| 317 SS Precistion Ground Bar | ASTM A276 317 Threaded Bar |
| 317 SS AISI Rebar | JIS SUS 317 True Bar |
| 317 SS Cold Drawn Bar | 317 SS Hot Rolled Bar |
| ASTM A479 317 SS Rods | DIN 1.4449 Half Round Bar |
| JIS SUS 317L Polish / Bright Bar | WERKSTOFF NR. 1.4438 Black Bar |
| DIN 1.4438 Angle Bar | UNS S31703 Forged Bar |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
|---|---|---|---|---|---|---|---|---|---|
| SS 317 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | 3.0-4.0 | 11.0-15.0 | 57.845 min |
| SS 317L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | 3.0-4.0 | 11.0-15.0 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Flat Bar | |||
|---|---|---|---|
| sizes in mm | Size (inch) | Thickness (mm) | Thickness (in Inches) |
| 22 | 7/8 | 17 & 18 | 2/3 – 5/7 |
| 25 | 1 | 5 to 20 | 3/16 – 4/5 |
| 30 | 1-3/16 | 5 to 20 | 3/16 – 4/5 |
| 32 | 1-1/4 | 6 to 20 | 1/4 – 4/5 |
| 35 | 1-3/8 | 5 to 20 | 3/16 – 3/16 |
| 40 | 1-4/7 | 5 to 25 | 3/16 – 1 |
| 45 | 1-7/9 | 5 to 25 | 3/16 – 1 |
| 47 | 1-6/7 | 17,25 & 32 | 2/3, 1 & 1-1/4 |
| 50 | 2 | 5 to 32 | 3/16 – 1-1/4 |
| 55 | 2-1/16 | 5 to 25 | 3/16 – 1 |
| 57 | 2-1/4 | 32 | 1-1/4 |
| 60 | 2-3/8 | 5 to 35 | 3/16 – 1-3/8 |
| 63 | 2-1/2 | 10 to 30 | 3/8 – 1-3/16 |
| 65 | 2-5/9 | 10 to 30 & 35 | 3/8 – 1-3/16, & 1-3/8 |
| 70 | 2-3/4 | 6 to 25 & 40 | 1/4 – 1, & 1-4/7 |
| 75 | 3 | 8 to 25 | 5/16 – 1 |
| 80 | 3-1/8 | 8 to 20 | 5/16 – 4/5 |
| 90 | 3-1/2 | 8 to 20 | 5/16- 4/5 |
| 100 | 4 | 8, 10, 12 | 5/16, 3/8, 1/2 |
| Square bar – metric sizes and weights | ||
|---|---|---|
| Square bar Size | KG’s per Metre | Standard Length (metres) |
| 10 x 10 | 0.81 | 6.0 |
| 12 x 12 | 1.16 | 6.0 |
| 16 x 16 | 2.06 | 6.0 |
| 20 x 20 | 3.22 | 6.0 |
| 25 x 25 | 5.03 | 6.0 |
| 32 x 32 | 8.24 | 6.0 |
| 40 x 40 | 12.8 | 6.0 |
| 50 x 50 | 20.12 | 6.0 |
| Documents like QAP | Packaging list |
| NABL approved lab test report | Guarantee letter |
| Buyers report | Third-party test report |
| Raw material test report | Material Traceability report |
| Commercial invoice to buyers | The TC like MTC as per EN 10204/3.1B |
Creative Piping Solutions Private Limited is focusing on every procedure to assure quality. AISI SS 317L Bars are subject to surface wash and cleaning to remove all impurities. After that bars and rods are wrapped in thin plastic. Then an outer rope is tied to protect the Stainless Steel Grade 317 Bar and they are packed in a container or wooden box.
