17-4 PH Round Bar
UNS S17400 17-4 PH SS Rod
Stainless Steel 17-4 PH Bars & Rods
17-4PH Steel is a chromium-nickel-copper precipitation hardening stainless steel used for applications requiring high strength and a moderate level of corrosion resistance like Aircraft and gas turbines, Nuclear reactor, Paper mills, Oil Fields, Chemical process components.
Creative Piping Solutions Private Limited is an ISO approved manufacturers and stockists of Stainless Steel 17-4 PH Round Bars and Rods. Our manufacturing unit is in compliance with the international quality standards which makes us in one of the top 17-4 PH Bright Hex and Square Bar exporters in India.
As one of the pioneering names in this sector, We manufacture commercial-grade, anti-corrosive, and rust-resistant UNS S17400 round bars and rods. ASTM A564 Flat and Hex Bars are known for their robust structure, high strength, and unique finish, ASTM A693 Grade 630 Square Bars are the most important components for some projects, some of the applications of 17-4 PH is Pump Shafts, Oil Patch, Mechanical Seals, Aerospace. At Creative Piping Solutions Private Limited, we carry out stringent quality testing processes for every single ASTM A705 Type 630 Bars.
We are leading Suppliers and Exporters of AMS 5643 Round Bars, Flat Bars, Square Bars, Hexagona Bars, Ture Bars, Angle Bars, Black Bars, Tee Bars, Polish Bars, Hot Rolled Bars, Cold Rolled Bars, Hollow Bars, Forged Bars, ground Bars, Threaded Bars, and Rods in Singapore, Bahrain, Kuwait, Iraq, Oman, Qatar, Saudi Arabia and the United Arab Emirates (UAE). These bars are widely used in industries such as Aerospace, Chemical, Food processing, General metalworking, Paper industries, Petrochemical, Petroleum, etc.
Popular Product Searches on Creative:
Square Bars | Forged Round Bar | Steel Hex Bar | Polish Bar | Bright Round Bars | Black Round Bars
| Specifications | UNS S17400, AMS 5643 |
| Product | 17-4 PH Round Bar |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Grade | 17-4 PH, UNS No. S17400, DIN 1.4542 |
| Finish | Black, Rough Turned, Bright Polished, Matt Finish, NO.4 Finish, BA Finish |
| Form | Round, Square, Rectangle, Hex (A/F), Ingot, Billet, Forging Etc |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Bright, Cold Drawn, Hairline, Polished. |
| Application | Chemical process, Petrochemical, Food processing, Pulp and Paper, Pollution control, Refining. |
| Condition | Cold Drawnd, Pulished, Centreless, Ground. |
| Round Bar Size | OD in the range of 4mm to 500mm |
| Bright Bar Size | OD in the range of 4mm to 100mm |
| Hex Bar Size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bar Size | 18mm – 47mm (11/16″ to 1-3/4″) |
| 17-4 PH SS Polished Round Bar | UNS S17400 17-4 PH T-Bar |
| WERKSTOFF NR. 1.4542 Square Bar | 17-4 PH SS Triangle Bar |
| ASTM A564 17-4 PH SS Flat Bar | AMS 5643 17-4 PH SS Hex Bar |
| 17-4 PH SS Hollow Bar | UNS S17400 Round Bar |
| 17-4 PH SS Precistion Ground Bar | ASTM A693 Grade 630 17-4 PH Threaded Bar |
| 17-4 PH SS AISI Rebar | JIS SUS 17-4 PH True Bar |
| 17-4 PH SS Cold Drawn Bar | 17-4 PH SS Hot Rolled Bar |
| UNS S17400 17-4 PH SS Rods | DIN 1.4542 Half Round Bar |
| AMS 5643 Polish / Bright Bar | ASTM A705 Type 630 PH 17-4 PH Black Bar |
| Alloy 17-4 PH Angle Bar | ASTM A564 17-4PH Forged Bar |
| Grade | C | P | Si | Ni | Cu | Fe | Mn | S | Cr | Cb+Ta |
|---|---|---|---|---|---|---|---|---|---|---|
| SS 17-4 PH | 0.07 | 0.04 | 1.0 max | 3.0 – 5.0 | 3.0 – 5.0 | Bal | 1.0 max | 0.03 | 15.0 – 17.5 | 5 X C / 0.45 |
Bar – Solution Annealed – Up to 100mm Dia. / Thickness
| Mechanical Property | Value |
|---|---|
| Tensile Strength | 1200 Max MPa |
| Hardness Brinell | 360 Max HB |
Bar – at P800 – Up to 100mm Dia / Thickness
| Mechanical Property | Value |
|---|---|
| Proof Stress | 520 Min MPa |
| Tensile Strength | 800 – 950 MPa |
| Elongation A | 18Min % |
Bar – at P930 – Up to 100mm Dia. / Thickness
| Mechanical Property | Value |
|---|---|
| Proof Stress | 720 Min MPa |
| Tensile Strength | 930 – 1100 MPa |
| Elongation A | 16 Min % |
Bar – at P960 – Up to 100mm Dia. / Thickness
| Mechanical Property | Value |
|---|---|
| Proof Stress | 790 Min MPa |
| Tensile Strength | 960 – 1160 MPa |
| Elongation A | 12 Min % |
Bar – at P1070 – Up to 100mm Dia. / Thickness
| Mechanical Property | Value |
|---|---|
| Proof Stress | 1000 Min MPa |
| Tensile Strength | 1070 – 1270 MPa |
| Elongation A | 10 Min % |
| Documents like QAP | Packaging list |
| NABL approved lab test report | Guarantee letter |
| Buyers report | Third-party test report |
| Raw material test report | Material Traceability report |
| Commercial invoice to buyers | The TC like MTC as per EN 10204/3.1B |
Creative Piping Solutions Private Limited is focusing on every procedure to assure quality. AISI SS 17-4 PH Bars are subject to surface wash and cleaning to remove all impurities. After that bars and rods are wrapped in thin plastic. Then an outer rope is tied to protect the Stainless Steel Grade 17-4 PH Bar and they are packed in a container or wooden box.
